ePropulsion NAVY 3.0 EVO electric outboard
ePropulsion NAVY 3.0 EVO electric outboard
Couldn't load pickup availability
The NAVY 3.0 is a 3kW (~6hp equivalent performance) electric outboard motor designed for performance and quietness. The brushless DC motor inside the NAVY 3.0 is placed at the bottom and surrounded by water allowing direct and effective cooling. A gearbox free design eliminates noise and maintenance requirements commonly seen with gas outboard motors.
The built-in motor protection slows or stops the motor when it collides with objects underneath the water. More time can now be spent enjoying the trip instead of spending hours or days with the mechanic! All of these features unite to create an electric outboard motor that is perfect for cruising, fishing and other water activities.
Includes:
- Navy 3.0 Outboard Motor Body
- Power and communication cables
Tiller or Remote Controller must be purchased separately.
| Shaft Length | Suits Transom Height |
|---|---|
| Short | - 50cm |
| Long | 50cm+ |
PRODUCT SPECS:
| Navy 3.0 Evo | Navy 6.0 Evo | |
|---|---|---|
| Power | 3 kW (6HP equivalent) | 6 kW (9.9HP equivalent) |
| Input voltage | 39V – 60V | 39 V – 60 V |
| Recomm. Battery | ePropulsion E-Series Battery | ePropulsion E-Series Battery |
| Motor Weight | 24.3 kg (short shaft) | 36 kg (short shaft) |
| Propeller | 10.2″ × 6.7″ 2-blade composite propeller | 12.6″ × 10.8″ 3-blade composite propeller / 13.4″ × 8.5″ 3-blade composite propeller / 12.6″ × 8.7″ 3-blade aluminum propeller (optional) |
| Trim / Tilt Angle | 0°, 5°, 10°, 15° / 60° | 0°, 5°, 10°, 15° / 60° |
| Shaft Length | Short, Long | Short, Long |
| Control | Evo Tiller / Evo Top Mount Control / Evo Side Mount Control / Evo Dual Remote Control | Evo Tiller / Evo Top Mount Control / Evo Side Mount Control / Evo Dual Remote Control |
| Hydro-generation | Yes | Yes |
| Motor | Brushless DC motor | Brushless DC motor |
| Direct Drive | Yes | Yes |
| Maintenance-Free | Yes | Yes |
