ePropulsion NAVY 6.0 EVO electric outboard

ePropulsion NAVY 6.0 EVO electric outboard

$5,740.00
$5,740.00
Sale Sold out
Taxes included. Shipping calculated at checkout.
Shaft Length

The NAVY 6.0 is a 6kW (~10hp equivalent performance) electric outboard motor designed for performance and quietness. The brushless DC motor inside the NAVY 6.0 is placed at the bottom and surrounded by water allowing direct and effective cooling. A gearbox free design eliminates noise and maintenance requirements commonly seen with petrol outboard motors.

  • Direct Drive (no gearbox)
  • Hydrogeneration
  • Virtually maintenance free


Using the low pitch propeller makes an ideal replacement for high thrust outboards and is capable of moving yachts around 3000kg at their hull speed. The Hydro-generation function is great for sustainable sailing experience.

Includes:

  • Navy 6.0 Outboard Motor Body
  • Power and communication cables

Tiller or Remote Controller must be purchased separately.


Shaft Length Suits Transom Height
Short - 50cm
Long 50cm+



PRODUCT SPECS:

Navy 3.0 Evo Navy 6.0 Evo
Power 3 kW (6HP equivalent) 6 kW (9.9HP equivalent)
Input voltage 39V – 60V 39 V – 60 V
Recomm. Battery ePropulsion E-Series Battery ePropulsion E-Series Battery
Motor Weight 24.3 kg (short shaft) 36 kg (short shaft)
Propeller 10.2″ × 6.7″ 2-blade composite propeller 12.6″ × 10.8″ 3-blade composite propeller / 13.4″ × 8.5″ 3-blade composite propeller / 12.6″ × 8.7″ 3-blade aluminum propeller (optional)
Trim / Tilt Angle 0°, 5°, 10°, 15° / 60° 0°, 5°, 10°, 15° / 60°
Shaft Length Short, Long Short, Long
Control Evo Tiller / Evo Top Mount Control / Evo Side Mount Control / Evo Dual Remote Control Evo Tiller / Evo Top Mount Control / Evo Side Mount Control / Evo Dual Remote Control
Hydro-generation Yes Yes
Motor Brushless DC motor Brushless DC motor
Direct Drive Yes Yes
Maintenance-Free Yes Yes
